DarwinFPV Baby Ape

DarwinFPV Baby Ape/Pro 142mm 3″ 2-3S FPV Racing RC Drone PNP 1104 430 …

(70 customer reviews)

Original price was: $226.08.Current price is: $69.56.

Affiliate Product.

More Information

Darwin Baby Ape has been loved by many pilots as soon as it was published. In order to design a better FPV drone, we upgraded the Baby Ape based on the pilots’ feedback and launched the BabyApe Pro V2. It is PNP Version, ELRS Version click here.

We made several upgrades to the frame. First of all, nylon standoffs are upgraded to aluminum alloy standoffs, which strengthens the frame and stables structure.

Second, We added the receiver fixing bracket.

Third, we upgraded the arms. The arms are upgraded from 4 individual arms(2.5mm thickness) to 2 integrated arms(3.0mm thickness). It is easier to disassemble, sturdy, and durable.

Last, the V2 version only needs 4 screws to fix, and the arm can be replaced by removing 2 screws without removing the whole drone.



Description:

Brand: DarwinFPV

Item Name: Baby Ape/Pro 142mm 3″ FPV Drone

Color: Yellow/Black/Purple

Weight: 71.6g

142mm Racing Frame Kit

Wheelbase: 142mm

Frame arm thickness: 2.5mm

Other thickness:1 .5mm

Frame kit material: 3K carbon fiber

1104 4300KV 2-3S Brushless Motor

KV: 4300KV

Lipo cell: 2-3S

Weight: 6.0g

AIO 4 IN115A BLHeli S ESC

Input voltage: 1-3SLIPo

Continuous current: 15A

Peak current:17A (10S)

BEC output: No

MCU: 48MHz EFM8BB21F16G

Protocol: DSHOY/Oneshot/MultiHhot

BLHeli-S Firmware target: S-H-50

Telemetry: No

Current Sensor: No

Main control chip: EFM8BB21

Firmware upgrade: Supports Dshot600 Oneshot125

MOS: 3*3

F411 AIO Flight Controller

Main control chip: STM32F411

Sensor: MPU6500

Integrated OSD

PPMDSM/IBUS/UAR share: UART1-RX

Mounting holes distance: 25.5*25 .5mm

Supports Betaflight firmware

Baro: No

Black Box: No

Baby APE Darwin700TVL Camera

Resolution:700TVL

Lens: 1.8mm

Input: 3.5-5V

TV System: PAL/NTSC

Baby APE Pro CADDX ANT Camera

Resolution:1200TVL

Mage Sensor: 1/3″ CMOS Sensor

Input: DC 3.7-18V

TV System: PAL/NTSC

5.8G 40CH 0mW/25mw/200mw switchable VTX

Supports TBS SmartAudio

Transmitting power: 0mW/25mW/100mW/200mW switchable

Channel: 40CH

Full video format: NTSC/PAL

Input voltage: 7V~24V

Power dissipation: +12V/600MW

Size: 25x20x6mm

Weight: S3.2g (except antenna)

With copper pipe mini antenna (Ipex antenna)

3016 3-blade propeller

Material: PC

Mounting hole: 1.5mm

Center thickness: 5.5mm

Quantity: 2 pairs

Weight: 1.18g a pair

Lipo Battery：Recommend 2-3S 300-450mah(Not included)

Receiver：PNP(without Receiver)



Package Included(Optional):

1x Baby Ape/Pro 142mm 3″ FPV Drone PNP







/>

/>

/>

/>

/>

/>

Anti-wind Ability /

Drone Weight /

Takeoff Weight /

Transit Time (Days) /

Camera Mount Type other

Indoor/Outdoor Use outdoor

color

Purple Ape

70 reviews for DarwinFPV Baby Ape/Pro 142mm 3″ 2-3S FPV Racing RC Drone PNP 1104 430 …

  1. Shanda Gatling –

    This little drone is such a treat to fly. It’s nimble and very responsive. I’ve only flown it in 2s so far, but I’m going to purchase some 3s and it should rip even better!

  2. Lelah Pelosi –

    Exactly as described!

  3. Emma Carra –

    I am also a friend of the kind, having set off the first trohi on the power of the foolishy, depriving him of the donor’s Yak, a certain priyshov with an unshimty polotnik, ale vlekspress compensating for the whole yak covered the new and the news

  4. Dieter Krist –

    It’s cool dronchik. Not remembering marriage. Iz minusiv scho treba dopayati Rx. Video on 3s badyoro free-stylitis.

  5. Franchesca Schwebach –

    The drone is cool, small, can fly outside
    I fly on 2s and it is very nimble, there will be an airplane on three cans))
    Ordered three pieces, the flight did not work on one, the microdrum of The 3,3 stabilizer is heated, it may have a problem or in the main chip which it supplies a short circuit, opened a dispute
    The seller does not go to contact
    They refused to provide a new flight or money for it
    Demanded return of goods
    Back through the mail, the shipment turned out to be $10, which no one will reimburse, consider this
    Although I myself would change the flight and that’s it

  6. Shante Dezern –

    Drone is already assembled. Propellers are a snap-on and will not accept screws since the whole on noname motors are in wrong place. I have not spun the motors but they should stay put.
    Props are GemFan Hurricane 3016-3. whit what it looks 1mm shaft.
    Have tried Gemfan WinDancer 3028-3 and they slack (1.5mm)
    I added ELRS 2.4 receiver and replaced the cable that was attached to Sbus.

  7. Zoraida Swick –

    Vizually, you are normal, you will not overdo it. Shvidko ruled, I recommend selling. I will be easier

  8. Micael Montes –

    I fly this drone a lot and I like it very much. I prefer biblade props nowadays.

  9. Ellie Julius –

    The original BabyApe was praised for its solid performance and value proposition, and its successor carries on this legacy.

  10. Renesmae Knapp –

    Taking the noble. Everything, yak in the inventory, a new set. There was a box, that neatly ziraniy drone. I’ll be tebuvati.

  11. Winston Hyde –

    This little drone is such a treat to fly. It’s nimble and very responsive. I’ve only flown it in 2s so far, but I’m going to purchase some 3s and it should rip even better!

  12. Daanyal Shepard –

    Exactly as described!

  13. Lorean Soni –

    I am also a friend of the kind, having set off the first trohi on the power of the foolishy, depriving him of the donor’s Yak, a certain priyshov with an unshimty polotnik, ale vlekspress compensating for the whole yak covered the new and the news

  14. Takako Ream –

    It’s cool dronchik. Not remembering marriage. Iz minusiv scho treba dopayati Rx. Video on 3s badyoro free-stylitis.

  15. Alfonso Villapol –

    The drone is cool, small, can fly outside
    I fly on 2s and it is very nimble, there will be an airplane on three cans))
    Ordered three pieces, the flight did not work on one, the microdrum of The 3,3 stabilizer is heated, it may have a problem or in the main chip which it supplies a short circuit, opened a dispute
    The seller does not go to contact
    They refused to provide a new flight or money for it
    Demanded return of goods
    Back through the mail, the shipment turned out to be $10, which no one will reimburse, consider this
    Although I myself would change the flight and that’s it

  16. Isadora Heer –

    Drone is already assembled. Propellers are a snap-on and will not accept screws since the whole on noname motors are in wrong place. I have not spun the motors but they should stay put.
    Props are GemFan Hurricane 3016-3. whit what it looks 1mm shaft.
    Have tried Gemfan WinDancer 3028-3 and they slack (1.5mm)
    I added ELRS 2.4 receiver and replaced the cable that was attached to Sbus.

  17. Coleen Dragon –

    Vizually, you are normal, you will not overdo it. Shvidko ruled, I recommend selling. I will be easier

  18. Anacleto Adornetto –

    I fly this drone a lot and I like it very much. I prefer biblade props nowadays.

  19. Lanie Edwin –

    The original BabyApe was praised for its solid performance and value proposition, and its successor carries on this legacy.

  20. Mahi Reid –

    Taking the noble. Everything, yak in the inventory, a new set. There was a box, that neatly ziraniy drone. I’ll be tebuvati.

  21. Samirah Hood –

    14 day to Lviv Ua. Really fast delivery.
    Thanks for saler.

  22. Clarita Pursell –

    Complete, well protected.
    Has no receiver, take it into account when buying

  23. Graham Rankin –

    The goods came in two weeks. They correspond the description. I’m satisfied and recommend the seller.

  24. Enrique Lutz –

    Good drone for beginners
    Very fast delivery
    There were problems with VTX, but the problem is solved if it is resoldered normally

  25. Tandy Hoyte –

    Everything is OK, delivery shvidka 14 days, the track has been vidslidkovya all hour, ale propelleriv spare parts in the sets of not.

  26. Olevia Lauder –

    Drone with a shvidko and a box of a bullet with a non-bruised one.
    In the sets of the scheme, the supply of gyntics and nuts, the type of screed and strep for accumultors.
    Before the drone, getting stronger with ELRS primach. With the first tests, it was impossible to spin one out of the motor, not all the cables and not all the cables. So it is not visible to me, I had a chance to shrink me by the controller and LED-strip. As a result, one of the conduction of the engine of the buoys did not solder and the motor did not work. It’s like pidpayav-everything is pratsyu.

  27. Thibault Silvestre –

    The parcel arrived in full and without damage.

  28. Roderick Roth –

    Perfect description, fast shipment. I bought a battery and ELRS (Darwing Cement) module separately – it works!

  29. Klemens Totleben –

    Great drone for training

  30. Carla Poole –

    excellent!!!

  31. Branda Goshorn –

    Great little drone, works well

  32. Emmanuel Gillie –

    Did not have time to play the backlash in one motor and it just took off and sat down

  33. Nour Hartman –

    bad stuff

  34. Ildefonso Sollami –

    it does not work at all

  35. Lakisha Mullenix –

    All OK, I recommend ………………………………………………………………………

  36. Kemberly Roza –

    All good, shvidka shipping …………………………………………………………………

  37. Rudolf Kirsch –

    Monster copter ……………………………………………………………………………

  38. Lisabeth Brennen –

    ……………………………………………………………………………………….

  39. Korey Wu –

    ……………………………………………………………………………………….

  40. Kholmatzhon Daniarov –

    Visually all ok. Tested motors and vtx with camera

  41. Jaimee Harter –

    For a first check all ok. Fast enough delivery. Budget small drone

  42. Demarcus Mcmullen –

    Perfect as in the description! Arrived very fast in Celorico from the Edge Pt. Very top drone, the factory configuration is very good, the drone flies very well and is very strong.
    I did a very basic test because, I don’t have the proper batteries so I tested it with a 1.550mAh tat, I thought it was not possible to fly but, it flew. Super recommend the seller and the product!

  43. Finn Junkermann –

    I will describe the seller. One for the budget copters themselves, those budget for someone else

  44. Fukumoto Shusake –

    The Troha box was broken during the transport, but otherwise everything is tsyle. Delivered close to Tizhden to the lion.

  45. Jaqueline Phipps –

    awesome little drone, easy to set up, added elrs ep2 rx, flys really well.

  46. Eleri Barnes –

    Top D + fast delivery, I only had a little setback on account of the receiver has to be SBUs!

  47. Marlen Akhmetov –

    The bomb drone is just super, for the coven the rocket is afraid of the robot power and role) a negative moment-Tse Zbirka in one of the engines of the zirvan in the result and the reason for the chottirokh gvintiv three, quarter buv just inserts… The camera is good for keruvannya superova obtatis for 3s, 850

  48. Windy Milnes –

    Good product arrived well but I have not yet proved it

  49. Susann Masson –

    Vizually, you are normal, you will not overdo it. Shvidko ruled, I recommend selling. I will be easier

  50. Wendi Raver –

    Delivery is fast, I take the fourth, all the norms
    The Mail delivers terrible, it’s good that the box is dense and fell into the void-there is a stupid hole in the box
    Tail already of another shape
    The scheme was not laid from this flight

  51. Gianmaria De Sario –

    Very cool!!! And still so cheap

  52. Germain Beaumont –

    A drone of kifovitz. Wartus your pennies on the 200%

  53. Armaan Ellison –

    Very top

  54. Alisa Watts –

    Very tiny,fast,and noisey. very fun

  55. Kathi Okamura –

    speedy

  56. Niam Mullins –

    All the Wrong Yak

  57. Wendelin Jonas –

    Very nice item, thank you.

  58. Ira Forster –

    Classic and Mich drone

  59. Starr Lheureux –

    thanks

  60. Patty Balser –

    I have a problem with binding but to.mo J the first drone but no manual. I don’t know how it flies…

  61. Rosalie Robertson –

    Shvidka delivery, packed in a simple bag, the box was damaged for an hour of transport. The goods are declared for the characteristics. Pink sales tsyna naizroza.

  62. Maximilien Chopin –

    ……………………………………………………………………………………….

  63. Gayla Tincher –

    The order was delivered very quickly.

  64. Lluciano Marcos –

    heavy for its size, cheepy engines, but nice to fly.

  65. Xose Mendez –

    Super thing.
    Having put the ELRS on the 2.4, the ring of trimaz for good is 500 m, Dali not litav-NEM de
    Z minusiv-not easily roztashuvannya kriplennya PID the antenna of the primach, with PADI props, half of the antenna was virvalo.
    Ale ce pitannya to the virobnik, not to the seller.
    On 3s to rush Sho Madna, TNT is more 50% giving all the time.

  66. Durante Sciara –

    All-in-law.

  67. Benoît Cortot –

    Having made, all pratsyu yak slide, tylki on Tsoi Nemo Rx

  68. Andrea Xiong –

    Flight characteristics are good; it is very easy to fly.

    This does not have a blackbox. However, if you use smartaudio with softserial, you can use it while switching between GPS and blackbox, which is rather convenient.

    The motors are affordable, easy to purchase, and simple to maintain.

    The only downside is the poor quality of the VTX. A range of 25mV to 100mV is too weak, resulting in improper video reception. It is recommended to use 200mV or higher regularly. Additionally, the camera angle cannot be adjusted due to interference with the camera connector. If these issues concern you, consider replacing the VTX with a smaller one.

    If you replace the screws with titanium, you can use a 3S 300mAh or 2S 450mAh battery, which weighs less than 100g.

  69. Savannah Brotherton –

    Fantastic product. It looks great for the price you have. Wishing volardo, I’m still setting up. Very happy for the purchase.

  70. Bonnie Montes –

    Below is a review of the Darkwinfp v racing drone with brushless motor.

    —

    Darkwinfpv’s brushless motorized racing drone is a great product that combines speed and stability. The operability as a remote control quadcopter is also outstanding, and the reaction is very fast. Thanks to the brushless motor, you can enjoy a powerful flight and withstand prolonged use. It is easy to assemble and recommended for a wide range of users from beginners to advanced. Perfect for competition and leisure, this drone is a very satisfying dish!
